Led button 16mm momentary 220V
  • Led button 16mm momentary 220V
  • Led button 16mm momentary 220V
  • Led button 16mm momentary 220V

Led button 16mm momentary 220V

FYBHEQ_LB-220V-FPW-red
Color
lei13.49
Tax included
Quantity
Product available with different options
0 Items

  We deliver to lockers!

Pick up your orders anytime, hassle-free!

  Fast Delivery!

Orders placed by 2:00 PM are shipped the same day. Delivered within 24h!

  2-Year Warranty

Reliable products, worry-free!

  Easy 14-Day Returns

Unused items? No questions asked!

Description

Overview

These chrome-plated metal buttons are rugged and look real good while doing it! Simply drill a 16mm hole into any material up to 1/2" thick and you can fit these in place, there's even a rubber gasket to keep water out of the enclosure. On the front of the button is a flat metal actuator, surrounded by a blue plastic LED ring. On the back there are 3 contacts for the button (common, normally-open and normally-closed) and 2 for the blue LED ring (+ and -). Connect 220V to the LED to have it light up nicely, there's a built in resistor!

Specifications

  • Drill hole diameter: 16mm
  • Switch contacts: 1 NO, 1 NC
  • Material: Chrome plated brass
  • Contact resistance: < 50 mOhm
  • Insulation resistance: > 1000 Mohm
  • Temperature: -20 C to +55 C
  • Mechanical life: > 500,000
  • Electrical life: > 50,000
  • Operating pressure: 1.5 - 5 N
  • Operating stroke: 1.5mm
  • Lamp rated voltage: 220V

3rIluVDEm5CLgE3LLOLnz2OVCvfOYHCr3b86XhFe

Product Details
FYBHEQ_LB-220V-FPW-red
0 Items

Filter list of variants by:
Color: Blue Green Red
Reference Color Quantity Availability Price Add to cart
FYBHEQ_LB-220V-FPW-red  Red  0 Out of stock lei13.49
add to cart
SHKOQD_LB-220V-FPW-blue  Blue  13 In stock lei13.49
add to cart
ZNXHPR_LB-220V-FPW-green  Green  38 In stock lei13.49
add to cart
