Product Description

The SIM800C (green PCB) GSM/GPRS module is a compact and reliable solution for IoT, telemetry, and remote control projects. It supports quad-band GSM (850/900/1800/1900 MHz), SMS, voice calls, and GPRS data, enabling quick integration into monitoring systems, SMS alerts, or simple data connections (HTTP/TCP/UDP).

The board includes a micro-SIM holder, an external antenna (included), and pins for UART, power, and status signaling. The rich SIMCom AT command set ensures easy and flexible configuration.

Important note: SIM800C requires 3.4–4.4 V (typically ~4.0 V) and current peaks up to ~2 A during transmission. Do not power it directly from 5 V; use a dedicated step-down converter and place low-ESR capacitors close to the power pins.

Technical Details

• Chipset: SIMCom SIM800C
• Networks: GSM/GPRS quad-band 850/900/1800/1900 MHz
• Services: SMS PDU/Text, voice call, GPRS multislot Class 10/12, TCP/UDP, HTTP/HTTPS* (depending on firmware and network), FTP*
• Interface: UART TTL (logic level ~2.8–3.0 V), configurable baud rate (commonly 9600/115200 bps)
• Power: 3.4 V – 4.4 V (typ. 4.0 V); peak current: up to ~2 A (bursts)
• Typical consumption: < 3 mA in Sleep; ~15–30 mA registered on network (variable)
• SIM: micro-SIM (1.8 V/3.0 V)
• Audio: pins for microphone and speaker (voice calls)
• Signaling/control: NETLIGHT (status LED), PWRKEY (power on/off), RST
• Antenna: external (included)
• Operating temperature: −40…+85 °C (per SIMCom)
• Module dimensions on PCB: ~25 × 23 mm (without antenna)

* Availability of data services depends on the operator and APN configuration; HTTPS/SSL support depends on the firmware version.

Recommended power:

• 4.0–4.2 V supply capable of ≥ 2 A peak (step-down from 5 V).
• Low-ESR capacitors near VCC: e.g., 470 µF + 100 nF.

Package Contents

• 1× SIM800C GSM/GPRS module on green PCB

• 1× Header pin set
